Bhagyoday Engineer is a leading exporter, supplier, dealer, trader, and manufacturer of Hydrochloric Acid storage tanks in Ahmedabad, India. We have a wide range of tanks to choose from, including FRP tanks, steel tanks, and concrete tanks. we are providing to customized tanks to meet the specific needs of their customers. Our network has in all over India and delivering to Chemical industry, Oil and gas industry, Food and beverage industry, Power generation industry, Mining industry, Construction industry.
What is Hydrochloric Acid storage (HCL) tanks?
Know about Hydrochloric acid storage tanks
Hydrochloric acid storage tanks are containers used to store hydrochloric acid, a corrosive liquid that can cause serious injury if it comes into contact with skin or eyes. These tanks are typically made of materials that are resistant to corrosion, such as polyethylene, fiberglass-reinforced plastic, or rubber-lined steel. They are also designed to prevent leaks and spills, as hydrochloric acid can contaminate the environment and pose a health hazard.
Below we have given you number of safety features
- Vents : to prevent pressure buildup and allow for the release of fumes
- Fume scrubbers : to remove harmful fumes from the air
- Secondary containment : to contain any spills or leaks
- Labeling : to identify the contents of the tank and provide safety instructions
They should be located in a well-ventilated area and away from heat sources. The tanks should also be inspected regularly for leaks or damage.
Here are some of the materials that are commonly used to make hydrochloric acid storage tanks :
- Polyethylene : Polyethylene is a strong and lightweight plastic that is resistant to corrosion. It is a good choice for small to medium-sized tanks.
- Fiberglass-reinforced plastic (FRP) : FRP is a composite material that is made of fiberglass and resin. It is strong, lightweight, and resistant to corrosion. FRP is a good choice for larger tanks.
- Rubber-lined steel : Rubber-lined steel is a type of steel that has a layer of rubber on the inside. The rubber layer protects the steel from corrosion and makes it safe to store hydrochloric acid. Rubber-lined steel is a good choice for tanks that will be exposed to harsh conditions.
| MODEL | FEATURES |
| Type | Liquid Chemical Storage/Process Tank. |
| Design | Standards |
| Model | 50 to 150 BBL HCL/Acid Tank (3 compartments) |
| Each Compartment | as per model |
| Tank Length | Max. 12 Meters |
| Tank Dia | max. 2.3 Dia Meters (Round Type Design) |
| Tank Rear & Front Side | Dish Head |
| FRP Linning Thickness | if required 5-6 mm Maximum |
| Tank Weight | as per model |
| Temperature | 30 to 80 c Max |
| Vacuum Set pressure | 2 PSI (Negative) |
| Tank testing | Pneumatic / Hydro 15 PSI |
